Self-Hosted GitHub Runners: My Journey to Reproducible Test Environments

Grazper, the company I work for, has recently decided to use GitHub as our developer platform. Perhaps because I don’t know how to say no, or maybe because my subconscious has a deep-dark love for DevOps, I took the lead on the whole migration and set up all our infrastructure around GitHub Actions. This is a summary of my journey so far, with the hiccups I’ve encountered along the way.

I believe this is a setup you might want to have in your company, your team, or even for your personal projects if you’re some kind of self-hosted nerd yourself. I hope you find this article useful. Throughout the guide, I’ll assume you’re somewhat familiar with GitHub Actions and know the basics of the syntax—enough to set up workflows on your own. Otherwise, their documentation is a good place to get started. Let’s dive in!

Our pre-requisites

• Our runners have to be self-hosted since we want to control the hardware the tests run on. Some require GPU acceleration, and we want to do performance tests on different platforms (Windows, Linux on x64 and arm64).
• We want our test environment to be reproducible. Tests should start from a clean slate and in the same environment every time.
• Maximum flexibility to the user of the test environment. You should be able to install, upgrade packages, and manipulate the test environment in ways that could potentially break the system.
• However, the self-hosted runner machine should handle this without actually compromising the machine itself.
• We want the simplest setup that can achieve all the above, to reduce maintenance cost and avoid an over-engineered solution.

For some organizations, it might be worth considering GitHub’s Actions Runner Controller, a Kubernetes operator that orchestrates and scales self-hosted runners. However, setting up something like this for our small company (~10 engineers) would be like using a bazooka to kill flies—and it would likely mean spending the rest of my career here solely maintaining this system. Plus, if the machine is powerful enough, you can just set up several runners in parallel. So, we’ll pass.

On self-hosted runners

In GitHub Enterprise, self-hosted runners can be registered at the enterprise, organization, or the repo level. This determines the scope your runner will have, i.e., which repos would be able to use it. The setup process, however, is the same.

Registering a self-hosted runner is pretty easy. Just navigate to Actions -> Runners in your settings and follow the instructions on the page. Once your self-hosted runner is configured, you can run it interactively with ./run.sh and check if it’s working. Then, you can execute a job on it by adding the runs-on: keyword to your workflow. Here’s a dummy action you can run:

# .github/workflows/dummy.yml
name: Dummy action

on:
  push:
    branches: master

jobs:
  dummy-job:
    runs-on: [self-hosted, Linux]
    steps:
      - name: say hello
        run: |
          echo hello, world!

Without any extra configuration, however, our action will get executed on “bare-metal” under the user that set up the runner, with its rights. This is a huge limitation for running tests because it means we only have one environment, and either we don’t allow users to alter it, or doing so is just the start of our descent down the nine circles of dependency hell.

Reproducible test environments

Docker containers

Unless you’ve been living under a rock, you’ve definitely heard of Docker—it’s like a lightweight version of a virtual machine, but instead of including an entire operating system, it just packs up your app and its essentials, making it way faster and more efficient to run anywhere, whether it’s on your laptop or in the cloud.

Luckily for us, GitHub actions has a good integration with Docker containers, and we can leverage them to achieve our precious reproducible environments. It’s “as simple” as entering the following keyword with the name of the image you want that job to run on. The runner will then pull the image (if it’s not in the machine’s cache already) and run your workflow inside a container:

#...
jobs:
  dummy-job:
    runs-on: [self-hosted, Linux]
    container: ubuntu
    steps:
      #...

This is extremely powerful: it solves our reproducibility issues and gives the action complete freedom to install, upgrade, remove packages as needed without damaging the external host. Docker is a very mature piece of software and there are heaps of images for all the use cases you can think of. On top of that, we can configure our custom Docker images, host them somewhere¹ and have a reproducible environment with all our dependencies. Nice! (Wait, what about the gpu?)²

I recommend taking a look at their documentation on how to run jobs in a container , for more information.

It’s reproducible now… Isn’t it?

Not so fast… If you run an action inside a container and take a closer look at how GitHub is spawning the containers in the action log (inside the Initialize containers step on Starting job container), you’ll find something similar to:

/usr/bin/docker create \
    --name 90e78535e458472585903and70a20877_ubuntu_a8ba9b \
    --label 836fe2 --workdir /__w/my-repo/my-repo \
    --network github_network_a7dd0070ad3346999fd4f51fd5d5059b \
    -e "HOME=/github/home" \
    -e GITHUB_ACTIONS=true -e CI=true \
    -v "/var/run/docker.sock":"/var/run/docker.sock" \
    -v "/home/myuser/actions-runner/_work":"/__w" \
    -v "/home/myuser/actions-runner/externals":"/__e":ro \
    -v "/home/myuser/actions-runner/_work/_temp":"/__w/_temp" \
    -v "/home/myuser/actions-runner/_work/_actions":"/__w/_actions" \
    -v "/home/myuser/actions-runner/_work/_tool":"/__w/_tool" \
    -v "/home/myuser/actions-runner/_work/_temp/_github_home":"/github/home" \
    -v "/home/myuser/actions-runner/_work/_temp/_github_workflow":"/github/workflow" \
    -entrypoint "tail" ubuntu "-f" "/dev/null"

Don’t get scared. What does all of this mean? Notice a couple of details:

• The runner is changing the HOME folder location of our container.
• It mounts the docker socket³.
• It mounts the runner’s _work folder, setting up the my-repo folder as the --workdir. This is where the code from our actions will get executed, and the runner doesn’t clean-up this directory after itself ⁴.
• The _work/_temp/_github_home folder gets mounted to the new home folder, and GitHub claims this _temp folder is cleaned up after every job. But hold your horses.

These mounts will always be the same for a project. Even worse than that, when running the action inside a container it’s fairly common that the user inside the container is root, so you know what happens when it writes to these volumes, don’t you? The host machine will see it as if root owns those files and the runner won’t even be able to clean up the _temp folder. Just to make it nicer, if you try, you won’t see any warning or error messages that this is the case, and you won’t notice until everything fails from having leftover garbage from 50 different tests/builds. Trust me, someone told me.

So how do I fix it?

There seems to be a way to configure how self-hosted runners spawn containers . However, as per September 2024, the page itself says:

Note: This feature is currently in beta and is subject to change.

If you have more severe requirements than we do, this might be your path. For us, luckily, there’s a much simpler way:

1. Configure the GitHub runner as root

This way it won’t have any permission issues when reading from the stuff written by docker volumes and the runner will be able to delete the _temp folder successfully. We can do so by installing the runner as a systemd service as root. To do so:

cd actions-runner
sudo ./svc.sh install root
sudo ./svc.sh start

2. Prevent jobs to run without a container

Having the runner as root means people would have the power to destroy our machine (picture a good ol' rm -rf /, or a much more twisted and … apt-get remove nvidia-driver-*). However, somewhere in the page to configure self-hosted runners they mention the existence of an environment variable, ACTIONS_RUNNER_REQUIRE_JOB_CONTAINER which we can set to true to prevent this.

To do so, append the following line to the actions-runner/.env file:

ACTIONS_RUNNER_REQUIRE_JOB_CONTAINER=true

3. Set up a cleanup job

As mentioned in their documentation , you can setup a cleanup job to run either at the start or the end of a job by setting ACTIONS_RUNNER_HOOK_JOB_STARTED or ACTIONS_RUNNER_HOOK_JOB_COMPLETED, respectively. I personally find it quite convenient to have access to the written files post-job for debugging purposes, so I’ll set up my cleanup job to run at the beginning. You’ll need to place your cleanup script somewhere outside the actions-runner folder.

#!/bin/bash

echo "Running cleanup.sh..."
# 1. Cleaning up work directory
if [ -d "$GITHUB_WORKSPACE" ] && [ "$(ls -A "$GITHUB_WORKSPACE")" ]; then
  echo "Cleaning up runner work directory: $GITHUB_WORKSPACE"
  rm -rf "${GITHUB_WORKSPACE:?}/"*
else
  echo "Runner work directory not found: $GITHUB_WORKSPACE"
fi

# 2. Pruning unused docker images
echo "Pruning unused docker images with docker image prune:"
docker image prune -f

Make sure your file is executable with chmod +x cleanup.sh, and append the hook to the actions-runner/.env file:

ACTIONS_RUNNER_REQUIRE_JOB_CONTAINER=true
ACTIONS_RUNNER_HOOK_JOB_STARTED=/path/to/cleanup.sh

And that’s it! With these few steps, you’ve achieved a self-hosted runner configuration that gives you full control of the hardware your tests run on, full control of the environment they run on, and the capacity to reproduce it at will. If you have been, thank you for reading! I hope this guide was useful to you!
